M16 x 35mm BZP Steel Projecting Bolt with Expanding Sleeve Anchor (16mm)

More Views

M16 x 35mm BZP Steel Projecting Bolt with Expanding Sleeve Anchor (16mm)
Excl. VAT: £1.66 Incl. VAT: £1.99
Show Price without VAT

Availability: In stock

SKU: APB1635
Thread 16mm (M16)
Overall Length 160mm
Drill Hole Diameter 25mm
Maximum fixture thickness 35mm
Fixture clearance hole 18mm
Embedment depth 110mm
Minimum drill hole depth 125mm
Installation torque 110 Nm
Material Zinc Plated
Pack size 1
    • Torque controlled shield anchor
    • Suitable for use in steel, non-cracked concrete, solid brickwork and solid concrete blocks
    • Ideal for overhead and ceiling work, securing cable trays, ducting and trunking or installing radiator brackets, partitions and structural fixtures
    • 16mm thread x 35mm maximum fixture thickness
