Galvanised Steel Wire Rope

Galvanised Steel Wire Rope

Galvanised Steel Wire Rope, SWR

Our Galvanised Steel Wire rope is available in a range of strands, sold per meter and on bulk buy value reels. Marine grade, it is very tough, durable and corrosion resistant, ideal for many different applications including maritime use, industrial and architectural applications such as rigging, hoists, winches and more. We have various strands and strengths of galvanised rope available:

1x19 Galvanised Steel Wire Rope is very stiff as it is made up of fewer wires, this is typically used for Balustrading and Architectural Rigging.

7x7 Galvanised Steel Wire Rope is a general use steel wire rope with medium flexibility.

7x19 Galvanised Steel wire rope is extremely flexible and suitable for load running applications such as Hoists and Winches.

Buy our wire rope per meter to your exact desired length or on pre cut 100 and 250 meter value reels for maximum savings.

We also supply a wide range of wire rope tools, clamp grips, ferrules and terminal ends. Here at GS Products, we are leading experts on Steel Wire Rope with everything you need for your project. Get in touch today if you have any questions, queries, or would like guidance on buying SWR.

Grid List

Set Descending Direction

8 Item(s)

  1. 7x7 Galvanised Steel Wire Rope Per Meter

    GALVANISED STEEL WIRE ROPE 7X7 STRAND

    Grade 1770 Galvanised Steel Wire Rope with a 7x7 construction is suitable for applications where high flexibility is not necessary

    Smaller diameters from 1mm-4mm 7x7 Steel Wire Rope are moderately flexible, 5mm and bigger diameters can be quite rigid

    7x7 Galvanised Steel Wire Rope is ideal as a general use Steel Wire Rope

    Common uses are Cateneray Steel Wire Rope, Marquee Steel Wire Rope and Security Applications

    PRICED PER METER, Simply add your required Meterage into the Quantity Box and we will send it to you in 1 Single Reeled Length Learn More

  2. 7x7 Galvanised Steel Wire Rope Value Reels
    Steel Cable Wire Rope with a flexible 7x7 construction 7x7 strand has 7 strands which are each made by 7 smaller stands, the 7x7 construction is very flexible in smaller diameter wires upto 3mm, 4mm and above in diameter will be stiff 1mm 1.5mm 2mm 3mm 4mm 5mm 6mm 8mm and 10mm 7x7 Galvanised Steel Wire Rope available in various size bulk reels to offer maximum value on larger projects Learn More
  3. 1x19 Galvanised Steel Wire Rope Per Meter

    1X19 STRAND GALVANISED STEEL WIRE ROPE

    1x19 Steel Wire Rope is a Stiff, Strong Steel Wire Rope and is often used for Rigging on Yachts, Architectural Type Steel Wire Rigging and Balustrading

    1x19 Galvanised Wire Rope is very stiff and has little stretch or flexibility

    1mm-5mm Diameter 1x19 Strand 1770 Grade Galvanised Steel Wire Rope

    1000's of Meters in Stock

    PRICED PER METER, Simply put the Meterage you require in the quantity box and it will be supplied in one Reeled Length Learn More

  4. 1x19 Galvanised Steel Wire Rope Value Reels
    1x19 Stiff Strand Galvanised Steel Wire Rope available on pre cut reels offer outstanding value for large projects

    Learn More
  5. 7x19 Galvanised Steel Wire Rope Per Meter

    GALVANISED STEEL WIRE ROPE 7X19 STRAND

    Extra flexible Galvanised 7x19 construction Grade 1770 Steel wire rope suitable where high flexibility & fatigue performance are important

    Typical applications for 7x19 Steel Wire Rope Usages are: Winches, Hoists, Security Cables and General Use

    The Steel Wire Rope 7x19 construction wire rope is a flexible steel wire rope which is suitable for most running load applications

    The 7x19 Strand Steel Wire Rope is our best selling strand of Steel Wire Rope due to it's high flexibility

    PRICED PER METER, Simply add your required Meterage into the Quantity Box and you will receive Your Steel Wire Rope in 1 SIngle Reeled Length Learn More

  6. 7x19 Galvanised Steel Wire Rope Value Reels
    7x19 is a very flexible strand of steel wire rope, it is made up of 7 main strands which in turn are made up of 19 smaller strands, the high number of small wires make this strand one of the best selling as it is easy to handle Available in bulk reels for maximum value in overall diameters of 3mm 4mm 5mm 6mm 7mm 8mm 9mm 10mm 11mm 12mm 13mm 14mm and 16mm Learn More
  7. 6x19 Fibre Core Galvanised Steel Wire Rope Value Reels
    Galvanised steel wire rope with a fibre core Available 6x19FC in diameters 3mm, 4mm, 5mm, 6mm, 7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 14mm, 16mm and 20mm This center of the steel wire rope is made of either natural fibers or polypropylene and offers greater elasticity than the independent wire rope core (IWRC) Learn More
  8. 19x7 IWRC None Rotating Galvanised Steel Wire Rope - Lubricated
    19x7 IWRC None Rotating Galvanised Steel Wire Rope - Lubricated Learn More

Grid List

Set Descending Direction

8 Item(s)



Q: I have never ordered Steel Wire Rope before...... what does 1x19, 7x7 7x19, 6x19fc mean?


A: 1x19, 7x7, 7x19 etc is the strand, this simply means how the steel cable has been wound. This gives the steel wire rope different and unique characteristics. The more strands in the wire rope overall diameter will make it more flexible, the lesser amount of strands will make it more stiffer



1x19 is made of 19 individual strands so this makes it a stiff wire rope - ideal for straight runs such as balustrades



7x7 is made up of 7 main strands and each of these 7 strands is made up of 7 smaller strands (49 small strands in total), this makes 7x7 a mid flex steel wire rope, it is flexible in 1mm, 1,5mm, 2mm, 2.5mm and 3mm diameter, 4mm diameter upwards in a 7x7 strand does get a little stiffer. This is a general use wire rope. 7x7 can be turned back on itself easily to make loops using our steel wire rope grips in diameters 1-4mm



7x19 is made up of 7 main strands but each of the 7 main strands is made up of 19 smaller strands (133 small strands in total), this makes the wire rope very flexible in all diameters. It is ideal for winches, pulleys and any application where you want general flexibilty in your steel wire rope. Most steel wire rope strands we sell over 5mm diameter is usually a 7x19 as 7x7 and 1x19 stranded steel wire ropes are very difficult to work as the diameter increases. 7x19 steel wire rope can easily be turned back on itself in all diameters








Q: Is the diameter the overall diameter regardless of 7x7, 7x19, 1x19 or any other strand?


A: Yes, regardless of the strand you decide to go with the diameter is the overall diameter

eg. 2mm 7x7 stainless steel wire rope has a 2mm overall diameter with a 7x7 strand







Q: How does the price per meter listing work?


A: If you out '25' into the quantity box we will send you a 25 meter continuous linear length
